| PUMP MODEL | GPM | PSI | RPM | HP | BORE | STROKE | SHAFT |
| PM11200R-EDM-E3 | 2.90 | 2900 | 3400 | 5.71 | 14 mm/0.551 in | 8.2 mm/0.322 in | Right |
Unloader Specifications:
- Bypass - Two available 3/8" NPT Female ports
- Inlet - Two available 3/8" NPT Female
- Outlet - 3/8" NPT Female
- Mounting port - 3/8" NPT Female bottom mounting port available
- Easy Start Version
- Shaft made of stainless steel for greater resistance to rusting and greater resistance to the torsional forces leading to longer life
- Main spring is guided through a thick spacer instead of a cheap washer
- Initial spike pressure is 30%, which is approximately a 23% reduced spike pressure compared to competitors.
- Max - 3,200 PSI
- Max - 12 GPM
- Max - 194°F temp rating
- Fits Pumps with 1/2" inlet and 3/8" outlet
WARNING This product can expose you to chemicals, including DINP and/or DEHP which is known to the state of California to cause cancer or birth defects or other reproductive harm, go to www.p65Warnings.ca.gov for more information. The products we sell are not intended for use in potable water systems and are only for industrial non-drinking water applications.
